Stages of Schnorkel installation

To ensure the productive operation of the car engine without failures and "choking" when driving on small bodies of water, it should be usedsnorkel. This device is a plastic pipe that is attached to the fender of the car and is intended for injecting air from the outside, not from the engine compartment. As a result, water hammers, which severely damage the connecting rods of the vehicle, are excluded.

The main advantages of an external air intake

• Prevents moisture from entering the car engine.It is mandatory to install a snorkel when driving often on off-road and small bodies of water. Otherwise, you can get serious problems. First, once in the middle of the ford, the car simply "sits" in it, and it will have to be rescued with the help of a winch or a tugboat. Secondly, even a minimal amount of water can cause damage to connecting rods, which can be restored only by completely overhauling the engine.
• Protects against dust.When moving on dirt roads, off-road and other places, the load on the air filter increases significantly. This fact contributes to excessive clogging of the filter element and deterioration of traction. However, this problem is easily solved by installing an external air intake.
• Improves vehicle dynamics.By installing an air intake, you can significantly reduce the fuel consumption of the car. This happens due to the increase in efficiency through a strong influx of cool air into the motor.

Installing a snorkel is a sequence of actions

Before starting to install the snorkel, you need to make sure you have the necessary tools and consumables. As a rule, installation does not do without the following devices:

• 10-millimeter drill and 4-millimeter drill;
• electric jigsaw;
• polyurethane sealant;
• anti-corrosion primer;
• masking tape;
• rulers;
• marker;
• rivet gun;
• set of wrenches.

The toolkit is prepared - you can start the installation, which consists of the following stages:

1. First of all, remove the wheel and wing protection located on the side of the snorkel to be installed. We use a jack to lift the car;
2. Next, we disconnect the air filter tank and the nozzle responsible for air injection;
3. Then - we determine whether the snorkel fits tightly to the car. To check this - we fit it to the body, mark the contours and evaluate the holes formed;
4. Next - measure the diameter of the inlet gap on the snorkel (mark in the form of a circle of the appropriate diameter (plus 1-2 mm));
5. Drill a hole in the middle of the circle using a 4 mm drill bit. After that - use a jigsaw to make a hole of the previously indicated diameter;
6. Let's not forget about fastening the body part. Using a drill, 10 millimeters long, we make slits in the wing of the car and treat them with a primer on the edges;
7. Following this - we install the external air intake and fasten it with bolts;
8. We complete the installation by sealing the inlet pipe and connecting it (we use a corrugation) to the air filter tank. The two edges of the corrugation are securely tightened with clamps.

Importantly!Be sure to check the snorkel for serviceability. To do this, start the car engine and put a plastic bag to the head. If all is well with the tightness, the bag will tear under the flow of air sucked by the snorkel. Otherwise, re-examine all connections and seal them.

If you often drive on dusty roads, then a snorkel is not an additional, but even a mandatory design to ensure the protection of the car. Which model to buy and which manufacturer to prefer - decide for yourself. However, remember that the productive operation of the air intake also depends on the correct installation. Therefore, we strongly recommend not to do it yourself, but to contact specialized services for a correct and, most importantly, safe installation.
